NANO-ITX · 120×120 MM · R101

UT100NU Industrial Motherboard

Name: UT100NU Industrial Motherboard
Brand: GEOLiNK
SKU: UT100NU

The flagship of the NANO line: onboard 28W Intel Core Ultra 5 125H / Ultra 7 155H (Meteor Lake) with dual-channel DDR5-5600 up to 96 GB, dual i226-V 2.5G Ethernet and six serial channels — desktop-class compute condensed to 120×120 mm for edge deployments.

Get a Quote Compare NANO-ITX

UT100NU · Quick Specs

CPU	Onboard Core Ultra 5 125H / 7 155H, 28W
Memory	2× DDR5-5600 SO-DIMM, up to 96GB
Display	HDMI 2.1 4K · DP 2.1 4K
Network	2× Intel i226-V 2.5G
Power	DC 12–19V, 120W
Temperature	−20/+60°C operating

CORE ULTRA 28W · DDR5-5600 96GB · DUAL I226-V 2.5G · 6×COM · DC 12–19V · SAMPLE MOQ 1 PC

Why UT100NU

Core Ultra where nothing else fits

Platform

28W Meteor Lake onboard

Core Ultra 5 125H or Ultra 7 155H on UEFI firmware — the strongest CPU this 120 mm form factor carries, for inference-adjacent edge and vision workloads.

Memory

DDR5-5600, up to 96GB

Two SO-DIMM slots at 5600 MHz give virtualized edges and analytics boxes the same memory headroom as a 170 mm board.

Networking

Dual i226-V 2.5G

Two adaptive Intel 2.5G controllers, 4× USB 3.0 and a Type-C — enough pipe for camera streams and control traffic on separate networks.

Field Service

One-key restore, AT/ATX

A dedicated RST one-key restore path plus REST_SEL and AT/ATX jumpers let integrators define power-on and recovery behavior for unattended sites.

Full Specifications

Technical data

Per the UT100NU English specification sheet (revision R101). Specifications can be verified against the datasheet on request.

Model	UT100NU · revision R101 · NANO motherboard 120×120 mm · UEFI BIOS
CPU	Onboard Intel Core 14th Gen Ultra 5 125H / Ultra 7 155H (Meteor Lake) · 28W TDP
Memory	2× DDR5 SO-DIMM · 5600 MHz · up to 96 GB
Storage	1× M.2 M-Key 2280 (PCIe 4.0 x4 & SATA 3.0) · 1× SATA 3.0 (2-pin 5V power)
Display	1× HDMI 2.1, 4K@60Hz · 1× DP 2.1, 4K@60Hz
Network	2× Intel i226-V 2.5G Ethernet adaptive
USB	4× USB 3.0 · 1× Type-C (USB 3.0) · 2× USB 2.0 pin headers, 4× USB 2.0 (keyed / anti-misinsertion)
Serial	2× DB9 male · 4× RS232 pin header (BOM optional RS232/RS485 mode)
GPIO	1× GPIO pin header, 8 channels input/output
Expansion	1× M.2 E-Key (PCIe 3.0 + USB 2.0 + CNVi, WiFi/BT) · onboard TPM 2.0 optional
Cooling	1× 4-pin PWM CPU fan (1.25 mm pitch) · 1× 4-pin PWM SYS fan (2.54 mm pitch)
Headers	2-pin CL_CMOS · 3-pin REST_SEL (one-key restore / reset) · AT/ATX header · FP1 (PWR/RESET/LEDs) · 3-pin power-burn · wired battery · buzzer
Power	DC 12–19V input · 120W
Dimensions	120 × 120 mm · board approx. 345 g with heatsink
Environment	−20°C to +60°C operating, 0–90% RH non-condensing · −40°C to +85°C storage, 0–90% RH non-condensing
Software	Windows 10 · Windows 11 · Linux

Where It Fits

Edge inference and dense I/O pods

The UT100NU is for workloads that used to need a Mini-ITX: local AI inference, multi-stream vision and virtualization, now available in a 120 mm board. Typical deployments:

Edge vision boxes: Core Ultra for on-prem image inference, dual 2.5G to carry camera feeds, 96GB for large model footprints.
Security gateways: six serial channels for access panels and alarms, GPIO for door strikes, Type-C for local maintenance.
Industrial PC replacements: DB9 COM to legacy PLCs and instruments while HDMI 2.1 and DP 2.1 drive dual 4K operator screens.

Edge AI gateway hardware in a security monitoring context

Configuration

Ordering options

Selectable options are configured at order time against a standard base board.

Option	Standard	Optional
CPU	Core Ultra 5 125H (28W)	Core Ultra 7 155H (28W)
Security	TPM 2.0 off	Onboard TPM 2.0 enabled
Serial mode	4× RS232 pin header	BOM: RS232/RS485 selectable mode
